SYW2M series compact design double deck manifold with side or bottom outlet

The SENYA SYW2M Series represents a pinnacle of efficiency and design intelligence in the realm of pneumatic control systems. As a modular solenoid valve manifold, it is engineered to streamline complex piping layouts and significantly reduce overall project costs. A primary feature of this series is its high degree of configurability, offering a selection of bank configurations including 4, 6, 8, 10, 12, and 14 valves in a single, integrated unit. This modular approach is fundamental to its cost-saving benefits. By consolidating multiple valves into one compact manifold, the system drastically minimizes the need for extensive individual piping runs, a multitude of connectors, and the associated labor hours for installation and maintenance. This not only accelerates machine build times but also reduces potential leak points, enhancing overall system reliability.

Central to the SYW2M’s design is a common main air supply passage that runs through the entire manifold block. This shared primary air path ensures consistent pressure supply to all valve modules from a single inlet point, simplifying the initial setup. However, to guarantee that every solenoid valve in the manifold receives an adequate air supply—especially critical in larger, high-flow-demand configurations—the SYW2M series incorporates an innovative feature. For manifolds with 8 or more valve stations, an additional pressurization port is provided. This allows the system to be supplied with compressed air from both ends of the main passage, effectively eliminating any potential pressure drop across the length of the manifold. This ensures that even the furthest valve in the bank can operate at its full rated flow and performance capacity, which is crucial for maintaining synchronized and powerful actuator movement in automated machinery.

Further enhancing its versatility, the SYW2M manifold provides flexible exhaust options. Users can configure the manifold to exhaust spent air either from the bottom or from the side of the unit. This flexibility is invaluable during the machine design phase, as it allows engineers to route exhaust lines in the most efficient and tidy manner, accommodating different spatial constraints and helping to keep the system layout clean.

Installation is remarkably straightforward. The manifold block is designed with four through-hole mounting points at its corners. This robust design allows for direct and secure attachment to a machine frame or side panel, saving the need for additional mounting brackets and simplifying the integration process. Furthermore, the “bilateral” nature of the manifold is a key advantage. The common main air supply passage can be connected from either side of the unit. This bilateral connection capability offers immense practical benefits on the production floor, providing greater freedom in pneumatic line routing and making the manifold adaptable to a wider range of machine layouts without requiring complex plumbing solutions.

In summary, the SENYA SYW2M Series Bilateral Modular Solenoid Valve Manifold is an optimal solution for modern automated equipment, delivering unparalleled integration, ensured performance for all valve stations, and exceptional installation flexibility.
